Diffusion Pump Oil

Vaccum Diffusion Pump Oil Advance Industries 702

Diffusion Pump Oil Advance Industries 704 is a colorless transparent oily, single-component fluid designed for high vacuum of 10-7torr (untrapped). It performs well in tough, rugged applications and offers quick pump down, even after exposure to air at operating temperatures. Advance Industries 704 is thermally and chemically stable allowing it to keep pump jets free of tars and hard carbon.

Technical Index:

• Chemical composition: Tetramethyl tetraphenyl trisiloxane
• Ultimate Vacuum, torr (untrapped): 10-7~10-8
• Saturated Vapor Pressure, torr : 5x10-8
• Specific Gravity: 1.06 ~ 1.07
• Viscosity (25°C), cSt: 38±3
• Flash Point °C: ≥210
• Refractive Index 25°C: 1.5500~1.5600
• Congealing Point °C: -35
• Molecular Description: 484

Application:
Diffusion Pump Fluid Advance Industries 704 can be used in variety of applications, including:
Electrical and electronics industry

• TV tubes, fluorescent tubes, cathode ray tubes
• ordinary bulbs
• capacitors
• rectifier metallised film vacuum system

Optical industry

• surface improvements
• anti reflective coatings
• optical filters and mirrors

Metallurgy industry

• high-vacuum furnaces
• melting, degassing and sintering refractory metals; thick-film deposition

Plastics industry

• surface improvements
• mirror coatings
• protective coatings
• film coatings

Other industries

• processing metals and fuels
• accelerators
• molecular plants
• R & D plants
• mass spectrometry

Others
Be used as transmission fluid in high-temperature carriers and various instruments.
Package, Transportation & Storage：

• Diffusion Pump Oil Advance Industries 704 is available in 1kg plastic bottles,1gallon plastic drums, 5kg plastic drums, 25kg plastic drums, 25kg Iron drums or 200kg Iron drums.
• Transport as non-hazardous chemicals, keeping away from rain and sunlight.
• Shelf life: 3 years.
